M760QTransceiver

Clear. Compact. Certified.

* Suitable for Light Sports and Experimental Aircraft

M760QTransceiver

Following on for Microair’s success as the manufacturer of one of the world’s smallest panel mounted VHF aircraft radios and with radios sold in over 20 countries around the world.

Microair’s latest version REV Q Radio is packed with features that include:-

SL30 Interface
Internal vox intercom with auxiliary audio (music) automatic mute
Dual Monitoring (Active/Standby)
Selectable Carrier Detect (PTT) – Lockout (safety feature)
99 programmable memories
Priority Key
Larger knobs
Alpha /Numeric Display
5 watts RF carrier output
Memory Sort by Name
Receiver tuning down to 108 Mhz.
1 Year Warranty as standard
Australian Manufactured

All this fits in a 57 mm (2 1/4”) instrument hole and weighs 416g (14.67oz).

TECHNICAL SPECIFICATIONS

Radio:
Channels (Transmit):

Channels (Receive):

Frequency Selection:
Frequency Display:

Memories:

Dual Motor:
Power Consumption:

Input Voltage:

Power Output:
VSWR Tolerance:
Receiver Sensitivity:
Receiver Selectivity:
Squelch Range:
Data Interface:
Speaker Volume Output:
Headset Volume Output:

Auxiliary Audio Input:
Temperature Range:

Dimensions:

Exposed Dial Face:

Weight:

Certified Aircraft Transceiver
760 channels, 25KHz spacing 118.000 – 136.975MHz
1160 channels, 25KHz spacing 108.000 – 136.975MHz
Concentric dials for MHz and kHz
2 line alpha/numeric LCD display (with back-lighting)

99 programmable memories

100ms Scan Time
Receive (no signal, no backlight) 140 mA
Transmit 1.9 A

10.7 – 16.0 Volts

5 watts (nominal)
2:1 for best operation (5:1 without damage)
-12dB SINAD @ 0.3uV (1KHz audio with 70% modulation)
70dBm
0.5 – 10.0uV
RS232
Nominal 4 watts output to 4 ohms
100mW into 150 Ohms (maximum audio output)
60mW into 300 Ohms
30mW into 600 Ohms

Line-level audio
From -20 to +55 degrees Celsius

65mm wide x 59mm high x 135mm deep
(2.6” wide x 2.3” high x 5.3” deep)

57mm diameter
2 ¼” diameter

416 grams (14. oz)

Radio:

Certified Aircraft Transceiver

Channels (Transmit):
760 channels, 25KHz spacing 118.000 – 136.975MHz
Channels (Receive):
1160 channels, 25KHz spacing 108.000 – 136.975MHz
Frequency Selection:
Concentric dials for MHz and kHz
Frequency Display:
2 line alpha/numeric LCD display (with back-lighting)

Memories:
99 programmable memories

Dual Motor:
100ms Scan Time
Power Consumption:
Receive (no signal, no backlight) 140 mA
Transmit 1.9 A

Input Voltage:
10.7 – 16.0 Volts

Power Output:
5 watts (nominal)
VSWR Tolerance
< 2:1 for best operation (5:1 without damage)
Receiver Sensitivity:
-12dB SINAD @ 0.3uV (1KHz audio with 70% modulation)
Receiver Selectivity:
70dBm
Squelch Range:
0.5 – 10.0uV
Data Interface:
RS232
Speaker Volume Output:
Nominal 4 watts output to 4 ohms
Headset Volume Output:
100mW into 150 Ohms (maximum audio output)
60mW into 300 Ohms
30mW into 600 Ohms

Auxiliary Audio Input:
Line-level audio
Temperature Range:
From -20 to +55 degrees Celsius

Dimensions:
65mm wide x 59mm high x 135mm deep
(2.6” wide x 2.3” high x 5.3” deep)

Exposed Dial Face:
57mm diameter
2 ¼” diameter

Weight:
416 grams (14. oz)
